广泛用于锡、钨、铅、金等有色、黑色、稀土等矿石重选作业，入选颗粒2-0.019mm。
◎The table surface is smooth, good abrasion resistance, durable, not easy deformation, easy to repair;
◎The asymmetry of the table movement is large, and wide differential regulation pattern to adapt different feed size and sorting requirements.;
◎table-side mechanism reliable ,less easy wear parts, and no oil leakage.
Range of use
Widely used in tin, tungsten, lead, gold and other non-ferrous, black, rare earth ore's gravity separate operation, selected particles 2-0.019mm.
Model | coarse Sand table surface | Fine sand table surface | notch groove table surface | ||
Size of table surface（mm） | 4436×1825×1536 | ||||
Stroke（mm） | 16～22 | 10～16 | 10～16 | ||
Jig frequency （r/min） | 240～290 | 300～320 | 330～340 | ||
Water consumption（t/h） | 190 | 80 | 50 | ||
Processing capacity（t/h） | 30 | 8 | 8 | ||
Feed size of ore（mm） | 2～0.2 | 0.5～0.037 | 0.074～0.019 | ||
Ore concentration（%） | 20～25 | 15～20 | 15～20 | ||
Minimum installation slope（°） | 2°30” | 1°50” | 0°45” | ||
Overall dimension（mm） | 5454×1825×1242 | ||||
Stroke adjustable range（mm） | 8～22 | ||||
Power （kW） | 1.5 | ||||
Weight（kg） | 1012 | ||||
