Specifications | Nominal volume (L) | Actual volume (L) | Heat exchange area (m 2) | Design pressure (MPa) | Stirring motor power (kw) | Weight （kg） |
| 50L | 50L | 70 | 0.54 | 0.4/0.6 | 0.75 | 486 |
| 100L | 100 | 127 | 0.84 | 1.1 | 552 | |
| 200L | 200 | 247 | 1.5 | 1.5 | 704 | |
| 300L | 300 | 369 | 1.9 | 2.2 | 945 | |
| 500L | 500 | 588 | 2.6 | 2.2 | 1104 | |
| 1000L | 1000 | 1245 | 4.5 | 4 | 2085 | |
| 2000L | 1500 | 1714 | 5.8 | 5.5 | 2550 | |
| 3000L | 2000 | 2179 | 7.2 | 7.5 | 2782 | |
| 4000L | 3000 | 3380 | 9.3 | 11 | 4068 | |
| 5000L | 5000 | 5435 | 13.4 | 15 | 5724 |
