GMZ centrifugal slurry pump

Home Products Hydrometallurgical Equipment and Pumps Pumps

Online consultation

GMZ type centrifugal slurry pump is a single-stage single suction cantilever centrifugal and axial suction pump. Widely used in metallurgy, mining, electric power, coal mine, water conservancy, chemical industry, etc. It could transport a large amount of abrasive and corrosive solid material liquid

The flow components made of high strength wear-resistant material, the seal part has three forms: the deputy leaves' shaft seal, packing seal, mechanical seal

Please indicate the type,quantity,flow and the head of delivery

型号	Flow (m3 / h)	Head (m)	Speed (r / min)	Head of delivery Value (m)	Efficiency (%)	Motor m3 / h L / S
						Model	Power (kW)
GMZ80-30-70	35	37.7	1470	4	34	Y180M-4	18.5
	70	34			52
	85	32			54
GMZ80-30-80	40	35	1470	4	44	Y180M-4	18.5
	80	34			55
	100	30			57
GMZ100-18-170	90	21	970	4.5	54	Y200L2-6	22
	170	16			56
	200	14.5			60
GMZ100-24-120	60	26.8	980	4	43	Y225M-6	30
	120	24			62
	140	23			66
GMZ100-25-200	100	30	1470	4.8	55.5	Y200L-4	30
	200	25			64.6
	220	22			58.5
GMZ100-27-140	70	31	1470	4.5	53	Y200L-4	30
	140	27			63
	170	24			62
GMZ100-30-80	40	34.2	970	3.5	35	Y200L2-6	22
	80	32.2			55
	100	20.2			39.5
GMZ100-30-140	80	35.5	1470	3.8	41	Y200L-4	30
	140	33.7			54.4
	160	33			56
GMZ100-30-200	100	34	1480	4.8	53	Y225S-4	37
	200	30			64
	240	28			63
GMZ100-35-250	130	38	1480	5	54	Y250M-4	55
	250	35			68
	300	28			71
GMZ100-40-50	30	40	1470	4.5	30	Y180L-4	22
	50	39			31
	60	37			36
GMZ100-40-200	120	53.7	1480	4.6	56	Y250M-4	55
	170	51			66
	200	44			70
GMZ100-50-120	60	55	1480	4.5	34	Y225S-4	45
	120	51			52
	140	49			43
GMZ100-52-80	40	56	1480	4	43.3	Y225M-4	45
	80	55			56
	100	53			58
GMZ100-60-80	40	64	1480	4	21	Y225M-4	45
	80	62.4			39
	120	60			49
